Description
ICON Alloys is proud to introduce our latest wheel design, the ‘Compass’. Featuring a modern 8-spoke design, sharp lines, a vented rock ring, and ICON-optimized dimensions, this new wheel is not only designed to improve the looks of your Jeep, truck, or SUV, but the overall function as well.
Available in all-new Satin Brass and classic Satin Black finishes, the Compass has a style that is anything but ordinary. Staying true to the ICON Alloys approach, the 17 Inch Compass has been engineered to maximize caliper clearance and optimize wheel position for un-hindered suspension travel and steering function.
Backspace and wheel offset dimensions have been strategically developed to reduce scrub radius, improving all-around handling and ride quality. The ICON Alloys Compass has also been strength tested to yield a 2,750lb load rating - making it one of the strongest wheel options on the market.
With build features such as these, it's clear that a set of ICON Alloys Compass wheels is the perfect complement to an ICON Vehicle Dynamics suspension system.
Features:
- Application-specific dimensions optimize vehicle dynamics and tire clearance
- Reduced unsprung weight and rotating mass improves on and off-road vehicle performance
- Aluminum alloy construction provides strength properties that are well suited for off-road use
Details:
- Backspacing: 5 Inch
- Bolt Pattern: 6 X 135
- Center Cap Included: Yes
- Color: Satin Black
- Construction: Cast
- Diameter: 17 Inch
- Finish: Powdercoated
- Inside Diameter: 87.1 MM
- Lug Hole Diameter: 1.1 Inch
- Lug Hole Quantity: 6
- Lug Nut Seat Type: Conical
- Material: Aluminum
- Maximum Load Rating: 2750 LBS
- Offset: 6 MM
- Positive Offset: 6 MM
- Split Type: No
- Spoke Quantity: 8
- TPMS Compatible: Yes
- TPMS Included: No
- Wheel Size: 17x8.5 Inch
- Width: 8.5 Inch
Application Summary:
- 2014-2025 Ford Expedition
- 2004-2025 Ford F-150
