Description
Taking its name from Southern California's picturesque Anza-Borrego desert, ICON Alloys returns to its roots with the all-new Anza wheel. Featuring a concave profile and deep stepped lip, you will be ready to take on the trails or look good on the streets in unique style.
Offered in a 17 Inch diameter, 8.5 Inch width, and multiple offsets, dialing in the Anza for your specific application will be a breeze. Available in the classic Satin Black, a smart Silver Machined, or an aggressive Gloss Gunmetal - there is a finish that has your name on it.
Look the part in any situation with the Anza wheel from ICON Alloys. Staying true to the ICON Alloys approach, the Anza has been engineered to maximize caliper clearance and optimize wheel position for un-hindered suspension travel and steering function.
Backspace dimensions and wheel offset have been strategically developed to reduce scrub radius, improving all-around handling and ride quality and making a set of these wheels the perfect complement to an ICON Vehicle Dynamics suspension system.
Features:
- Concave profile with deep stepped lip 17 Inch X 8.5 Inch in 5-lug & 6-lug bolt patterns Satin black powder coat finish for sleek looks and corrosion resistance
- Application-specific dimensions optimize vehicle dynamics and tire clearance
- Reduced unsprung weight and rotating mass improves on and off-road vehicle performance
- Aluminum alloy construction provides strength properties that are well suited for off-road use 2750lbs load rating
Details:
- Backspacing: 4.5 Inch
- Bolt Pattern: 5 X 5
- Center Cap Included: Yes
- Color: Satin Black
- Construction: Cast
- Diameter: 17 Inch
- Finish: Powdercoated
- Inside Diameter: 71.5 MM
- Lug Hole Diameter: 1.1 Inch
- Lug Hole Quantity: 5
- Lug Nut Insert Included: No
- Lug Nut Seat Type: Conical
- Material: Aluminum
- Maximum Load Rating: 2750 LBS
- Negative Offset: 6 MM
- Offset: -6 MM
- Rim Diameter: 17 Inch
- Rim Width: 8.5 Inch
- Split Type: No
- Spoke Quantity: 16
- Tires Included: No
- TPMS Compatible: Yes
- TPMS Included: No
- Wheel Lug Hole Quantity: 5
- Wheel Nuts Included: No
- Wheel Size: 17x8.5 Inch
- Width: 8.5 Inch
Application Summary:
- 2020-2024 Jeep Gladiator
- 2018 Jeep Wrangler JK
- 2010-2015 Jeep Grand Cherokee
- 2007-2023 Jeep Wrangler
